FA-OC-GYTS-96 , Armored Optical Fiber Cable GYTS For Outdoor Use
With Steel Or Aluminum Tape 96F
The GYTS or GYTA fiber optic cable is with metallic strengthen
member in the middle of the cable, the loose tube with high Young’s
modulus are stranded around the strengthen member and the colored
fibers and jelly are filled into the loose tubes and filling
compound are used to fill the space outside the loose tube and the
tubes are wrapped by a corrugated steel tape or APL and a PE sheath
is outside the tape to form a complete fiber cable.
Main Characteristics Of FA-OC-GYTS-96
The loose tube material is with good hydrolysis resistance and high
strength;
The tube is filled with gelatinous fillings, and provides critical
protection for the optical fiber;
PE sheath is with excellent anti ultraviolet radiation performance;
The single wire central strength member is benefit to the parallel
and stretching of the optical cable;
Fiberall GYTS fiber cable is with good performance on tensile,
abrasion resistance, impact resistance, crush resistance, repeated
bending, torsion, bending, cycling (angle less than 90 DEG) and
shooting, and so on;
With good mechanical and temperature performance;
The double sided corrugated steel strip (PSP) improves the anti
permeability capacity of the optical cable;
The utility cable model is with advantages of fast transmission,
long distance, good confidentiality, good electromagnetic
interference, good insulation, good chemical stability, long
service life and low loss, and has good characteristics and
economic benefits.;
It is suitable for long distance communication and inter office
communication;
Suitable laying methods: overhead, pipeline, direct buried;
Applicable temperature range: - 40 DEG C - +60 DEG C.
Optical Fiber Characteristics
| | G.652 | G.655 | 50/125 µm | 62.5/125 µm |
| Attenuation(+20℃) | @ 850 nm | | | ≤ 3.0 dB/km | ≤ 3.0 dB/km |
| @1300 nm | | | ≤ 1.0 dB/km | ≤ 1.0 dB/km |
| @1310 nm | ≤ 0.36 dB/km | ≤ 0.40 dB/km | | |
| @1550 nm | ≤ 0.22 dB/km | ≤ 0.23 dB/km | | |
| Bandwidth | @ 850 nm | | | ≥ 500 MHz·km | ≥ 200 MHz·km |
| @1300 nm | | | ≥ 1000 MHz·km | ≥ 600 MHz·km |
| Numerical Aperture | | | 0.200 ± 0.015 NA | 0.275 ± 0.015 NA |
| Cable Cut-off Wavelength | ≤ 1260 nm | ≤ 1450 nm | | |
Cable Specification
| Model | Fiber account | OD(mm) | Tube Qty | Nominal Weight(kg/Km) | Max. Tension (N) | Max. Crushing Resistance (N/100 ) |
| Short-term | Long-term | Short-term | Long-term |
| GYTS | 2--60 | 10.5±0.5 | 5 | 112 | 1500 | 600 | 1000 | 300 |
| GYTS | 62--72 | 11.5±0.5 | 6 | 138 | 2000 | 600 | 1000 | 300 |
| GYTS | 74--96 | 13.0±0.5 | 8 | 165 | 2000 | 600 | 1000 | 300 |
| GYTS | 98--144 | 15.8±0.5 | 12 | 222 | 2500 | 800 | 1000 | 300 |
The above value is for reference only. The true weight of optical
cable may have some tolerance due to different capacity.
