2U 19 Inch EPON OLT Optical Line Terminal With 8 PON Ports 8 Uplink
Ports
Our Optical Network Unit (ONU) and ONT Optical Network Terminal are
100% CE-RED certified and all of them are pass the below test :
| Test Item | Applied Standards | Test Report No. | Certificate number |
| Art.3.1 (a) | Health | EN 62479 | BST1704767530001Y-1ER-10 | BST1704767530001Y-1EC-1 |
| Art.3.1 (b) | Safety | EN 60950 | BST1704767530001Y-1SR-2 | BST1704767530001Y-1EC-1 |
| Art.3.1 (c) | EMC | ETSI EN 301 489 | BST1704767530001Y-1ER-1 | BST1704767530001Y-1EC-1 |
| Art.3.2 | Radio | ETSI EN 300 328 | BST1704767530001Y-1ER-7 | BST1704767530001Y-1EC-1 |
Please feel free to request the certificate or test report if it is
necessary when you evaluate our company and our product.
Key Specifications
Port Features
| 8 PON ports (1.25G) |
| 8 uplink ports (1G) (electronic ports and optical ports options) |
| 1 management ports (special software management) |
| 2 console port (leaflet PON board has a console port) |
| Each PON board has a management port |
| Physical Features | Frame: 19 inches 2U height |
| Physical dimensions (L x W x H): 485 x 286 x 90mm |
| Power supply: 100 to 240V AC or -48V |
| Power consumption: 60W |
Temperatures Range
| Working temperatures: 0 to 45 ℃ |
| Storage temperatures: -30 to 60 ℃ |
| Relative humidity: 10 to 90% (non-condensing) |
Product Features Of FA-EOLT8230
High density, flexible networking
PON maximum supports 2 boards, each board has 4 PON port, Up to 8
PON ports can be supported in the complete machine
Highly reliable case, strong adaptive capacity to environment
2U case, modular design, all modules can be hot plugged and online
update is supported
Redundant power, redundant fans
Good shielding measures
Layer 2 aggregation switching
Layer 2 wire-speed forwarding; support rich layer 2 protocols
8K Mac address list in leaflets PON board
8 uplink ports, supports up to 4G uplink bandwidth via port
aggregation function
Uplink port supports electronic port modules and optical port
modules, which can be configured flexibly as required
Perfect network management function
Supports GUI based graphical interface and web interface management
Supports in-band management, out-of-band management
Supports online upgrade of device software
Strong QOS function
Supports flexible DBA, uplink and downlink traffic rate-limited
Supports IP ToS, IEEE802.1p
Port based traffic control, traffic shaping
Rich OAM function
Supports ONU automatic identification, automatic finding and
automatic registration
Supports the function of automatic loop back test to single link
Strong VLAN function, including VLAN stacking, trunk, translation,
flexible QINQ
Supports flexible controllable multicasting, support IGMP snooping
