FA-FSC-V2, Dome Type Fiber Optic Splice Closure Mechanical Sealing 4 Ports Max 96 Cores

During winding fiber, note the distortion direction of the optical fiber, generally is should be fallen "8" type, do not wring the fiber and avoid damage during covering and package. The fiber optic splice closure must be operated strictly according to the instruction and procedures, otherwise it may cause heavy losses. And must pay attention to the operation procedure of the splicing machine, and the length of the heat shrinkable tube shall be consistent with the requirements. After the fiber is spliced, the fiber should be protected by the heat shrinkable tube and the remaining fiber should be winded. During the process of winding fiber, the bending radius of the fiber can not be too small, generally not less than 40mm. If the bending radius is too small, it is easy to cause big refraction loss and increases dispersion. For a long time, the fiber may be broken. Specific operation requirements:

Wind 1.5 cycles of the optical fiber in the fiber tray, and then wind all the remaining fibers in the fiber splice joint closure.

2, Use single core buffer tube for single core fiber, and use ribbon buffer tube for ribbon fiber . Use nylon tie to tight the buffer at the inlet of the fiber splice closure.

3, Match two fibers or two fiber band according to the provisions and put the connection into the slot of the fiber tray, and wind the extra fiber in the fiber cassette.

Cover the upper plate and press it in place.

5, Use correct fiber tray according to the needs of different capacity, decided added number pf fiber cassette, the superposition type of fiber tray must conform to the slots unit for fiber connection and meet requirements of checking and maintenance .

Main Components Of FA-FSC-V2

Main Accessories And Special Tools
